tip35c tip36c tip36b.pdf datasheet:

TIP35CTIP36B/TIP36CCOMPLEMENTARY SILICON HIGH POWERTRANSISTORS STMicroelectronic PREFERREDSALESTYPESDESCRIPTION The TIP35C is a silicon Epitaxial-Base NPNtransistor mounted in TO-218 plastic package. Itis intented for use in power amplifier andswitching applications.3The complementary PNP type is TIP36C.2Also TIP36B is a PNP type. 1TO-218INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitNPN TIP35CPNP TIP36B TIP36CVCBO Collector-Base Voltage (IE = 0) 80 100 VVCEO Collector-Emitter Voltage (IB = 0) 80 100 VVEBO Emitter-Base Voltage (IC = 0) 5 VI Collector Current 25 ACI Collector Peak Current 50 ACMI Base Current 5 ABPtot Total Dissipation at Tcase 25 oC 125 WoTstg Storage Temperature -65 to 150 CoTj Max. Operating Junction Temperature 150 CFor PNP types voltage and current values ar
