Скачать даташит для ftp16n06a:

FTP16N06A N-Channel MOSFET Pb Lead Free Package and Finish Applications VDSS RDS(ON) (Max.) ID Automotive DC Motor Control 55V 16 m 65A Class D Amplifier Uninterruptible Power Supply (UPS) Features D RoHS Compliant Low ON Resistance Low Gate Charge Peak Current vs Pulse Width Curve G G D Ordering Information S S Package PART NUMBER PACKAGE BRAND Not to Scale FTP16N06A TO-220 FTP16N06A Absolute Maximum Ratings TC=25 oC unless otherwise specified Symbol Parameter Maximum Units VDSS Drain-to-Source Voltage 55 V (NOTE *1) ID Continuous Drain Current 65 ID@ 100 oC Continuous Drain Current Figure 3 A IDM Pulsed Drain Current, VGS@ 10V (NOTE *2) Figure 6 Power Dissipation 170 W PD o o Derating Factor above 25 C1.14 W/ C VGS Gate-to-Source Voltage 20 V Single Pulse Avalanche Engergy EAS 1200 mJ L=1mH IAS Pulsed
