AP12A390YT Halogen-Free Product Advanced Power DUAL N-CHANNEL ENHANCEMENT Electronics Corp. MODE POWER MOSFET D1 Simple Drive Requirement BVDSS 120V Fast Switching Characteristic RDS(ON) 390m D2 RoHS Compliant & Halogen-Free ID3 1.7A S1 G1 D1 D1 D2 D2 S2 G2 Description PMPAK 3x3 AP12A390 series are from Advanced Power innovated design and silicon process technology to achieve the lowest possible on-resistance and fast switching performance. It provides the designer with an extreme efficient device fo The PMPAK 3x3 package is special for voltage S1 G1 S2 G2 conversion application using standard infrared reflow technique with the backside heat sink to achieve the good thermal performance. Absolute Maximum Ratings@Tj=25oC(unless otherwise specified) . Symbol Parameter Rating Units VDS Drain-Source Voltage 120 V VGS Gate-Source Voltage +20
