Скачать даташит для ap3n9r5mt:

AP3N9R5MT Halogen-Free Product Advanced Power N-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET 100% Rg & UIS Test BVDSS 30V D Simple Drive Requirement RDS(ON) 9.5m Low On-resistance G RoHS Compliant & Halogen-Free D S D D Description D AP3N9R5 series are from Advanced Power innovated design and silicon process technology to achieve the lowest possible on- resistance and fast switching performance. It provides the designer with an extreme efficient device for use in a wide range of power S applications. S S G The PMPAK 5x6 package is special for DC-DC converters PMPAK 5x6 application and the foot print is compatible with SO-8 with backside heat sink and lower profile. Absolute Maximum Ratings@Tj=25oC(unless otherwise specified) . Symbol Parameter Rating Units VDS Drain-Source Voltage 30 V VGS Gate-Source Voltage +20 V D
