ASDM4976S 60V N & P-Channel PowerTrench Features Product Summary High power and current handing capability N-Channel Lead free product is acquired BVDSS ID RDSON.max@10V Surface mount package 60V 40m 5A P-Channel Application BVDSS ID PWM applications RDSON.max@10V Load switch -60V 90m -4A Power management SOP-8 top view D1 D2 D2 ASCEND S1 S2 G2 G1 N-channel P-channel Absolute Maximum Ratings (TA=25 unless otherwise noted) Parameter Symbol N-Channel P-Channel Unit Drain-Source Voltage VDS 60 -60 V Gate-Source Voltage VGS 20 20 V 5 -4 A Continuous Drain Current ID A Pulsed Drain Current (Note 1) IDM 20 -15 Maximum Power Dissipation PD 2 1.2 W Operating Junction and Storage Temperature Range TJ,TSTG -55 To 150 -55 To 150 Thermal Characteristic N-Ch 89 Thermal Resistance,Junction-to-Ambient (Note2
