Скачать даташит для agm3416e:

AGM3416E Typical Electrical And Thermal Characteristics (Curves) Figure 1. Output Characteristics Figure 2. Transfer Characteristics Figure 3. Power Dissipation Figure 4. Drain Current Figure 5. BV vs Junction Temperature Figure 6. R vs Junction Temperature DSS DS(ON) www.agm-mos.com 3 VER2.68 AGM3416E Typical Electrical And Thermal Characteristics (Curves) Figure 7. Gate Charge Waveforms Figure 8. Capacitance Figure 9. Body-Diode Characteristics Figure 10. Maximum Safe Operating Area www.agm-mos.com 4 VER2.68 AGM3416E Dimensions SOT23-3 D MILLIMETER b SYMBOL MIN NOM MAX A 1.25 A1 0.03 0.10 A2 1.05 1.10 1.15 0.25 b 0.30 0.35 0.40 c 0.13 0.17 D 2.87 2.92 2.97 E 1.55 1.60 1.65 E1 2.70 2.85 3.00 e e 0.95 BSC. e1 e1 1.80 2.00 L 0.35 0.45 0.55 c 0 8 A DIM MILLIMETERS A 2.82 3.02 B 1.60 0.10 C 1.10
