Скачать даташит для agm3416el:

AGM3416EL Typical Electrical And Thermal Characteristics (Curves) Figure 1. Output Characteristics Figure 2. Transfer Characteristics Figure 3. Power Dissipation Figure 4. Drain Current Figure 5. BV vs Junction Temperature Figure 6. R vs Junction Temperature DSS DS(ON) www.agm-mos.com 3 VER2.68 AGM3416EL Typical Electrical And Thermal Characteristics (Curves) Figure 7. Gate Charge Waveforms Figure 8. Capacitance Figure 9. Body-Diode Characteristics Figure 10. Maximum Safe Operating Area www.agm-mos.com 4 VER2.68 AGM3416EL Dimensions SOT23 D b MILLIMETER SYMBOL MIN NOM MAX 0.25 A 0.90 1.15 A1 0.00 0.10 A2 0.90 0.95 1.05 b 0.30 0.40 0.50 c 0.15 0.25 D 2.85 2.90 2.95 E 1.25 1.30 1.35 e E1 2.25 2.40 2.55 e1 e 0.95 TYP. e1 1.80 2.00 c L 0.55 REF. L1 0.30 0.50 0 8 D DIM MILLIMETERS A 2.90 0.1 B 1.3
