AGM409D General Description Product Summary The AGM409D combines advanced trench MOSFET technology with a low resistance package to provide extremely low R . DS(ON) BVDSS RDSON ID device is ideal This for load switch and battery 40V 6.5m 63A protection applications. Features TO-252 Pin Configuration Advance high cell density Trench technology Low R to minimize conductive loss DS(ON) Low Gate Charge for fast switching Low Thermal resistance 100% Avalanche tested 100% DVDS tested Application MB/VGA Vcore SMPS 2nd Synchronous Rectifier POL application BLDC Motor driver Package Marking and Ordering Information Quantity Device Marking Device Device Package Reel Size Tape width AGM409D AGM409D TO-252 2500 330mm 16mm Table 1. Absolute Maximum Ratings (TA=25 ) Symbol Parameter Value Unit VDS
