Скачать даташит для asa60r090efd_asw60r090efd:

ASA60R090EFD, ASW60R090E ASW60R090EFD MOSFET Silicon N-Channel MOS 1. Applications Soft Switching Boost PFC switch,Half bridge or Asymmetric half bridge or Half bridge or Asymmetric half bridge or Series resonance half bridge and full bridge topologies. phase-shift-bridge(ZVS),LLC Application bridge(ZVS),LLC Application-Server Power, Telecom Power,EV Charging,Solar inverter Solar inverter. 2. Features Low drain-source on-resistance RDS(ON) resistance RDS(ON) = 0.080 (typ.) Easy to control Gate switching Enhancement mode Vth = 3 to 5V Table 1 Key Performance Parameters Parameter Value Unit V 650 V DS @ T j,max R 90 DS(on),max m Q 65 nC g,typ I 141 A D,pulse Body diode dv/dt 50 V/ns 3. Packaging and Internal Circuit Part Name Package Marking ASW60R090EFD TO247 ASW60R090EFD AS ASA60R090EFD TO220F ASA60R090EFD AS TO220
