Скачать даташит для asa60r280e_asd60r280e:

ASA60R280E, ASD60R280E , ASD60R280E MOSFET Silicon N-Channel MOS 1. Applications Boost PFC switch, single-ended flyback or ended flyback or two-transistor forward, HB or AHB or LLC topologies. For PC power, PD Adaptor, LCD & PDP TV, UPS application. LCD & PDP TV, LED Lighting, Server power, UPS application. 2. Features Low drain-source on-resistance RDS(ON) = resistance RDS(ON) = 0.257 (typ.) Easy to control Gate switching Enhancement mode Vth = 2.8 to 4.2 2 V Table 1 Key Performance Parameters Parameter Value Unit V 650 V DS @ T j,max R 280 DS(on),max m Q 22.94 nC g,typ I 45 A D,pulse 3. Packaging and Internal Circuit Part Name Package Marking ASA60R280E TO220F ASA60R280E ASD60R280E TO252 ASD60R280E TO220F TO252 TO252 ASA60R280E, ASD60R280E 1 Maximum ratings at Tj = 25 C, unless otherwise specified Table 2 Max
