Скачать даташит для asa60r330e_asd60r330e:

ASA60R330E, ASD60R330E , ASD60R330E MOSFET Silicon N-Channel MOS 1. Applications Boost PFC switch,single-ended flyback or ended flyback or two-transistor forward, Half bridge or Asymmetric half bridge or half bridge or Series resonance half bridge topologies. . PC power, PD Adaptor,LCD & PDP TV, Adaptor,LCD & PDP TV,LED Lighting,Server power,UPS application. 2. Features Low drain-source on-resistance RDS(ON) = 0. resistance RDS(ON) = 0.305 (typ.) Easy to control Gate switching Enhancement mode Vth = 2.8 to 4.2 4.2 V Table 1 Key Performance Parameters Parameter Value Unit V 650 V DS @ T j,max R 330 DS(on),max m Q 22 nC g,typ I 33 A D,pulse 3. Packaging and Internal Circuit Part Name Package Marking ASA60R330E TO220F ASA60R330E ASD60R330E TO252 ASD60R330E TO220F TO252 TO252 Released ASA60R330E, ASD60R330E 1 Maximum
