Скачать даташит для aun063n10:

AUN063N10 MOSFET Silicon N-Channel MOS 1. Applications Single-ended flyback or two-transistor forward topologies. PC power, PD Adaptor, LCD & PDP TV and LED lighting. 2. Features Low drain-source on-resistance RDS(ON) = 5.5m (typ.) Easy to control Gate switching Enhancement mode Vth = 2.4 to 3.4 V Table 1 Key Performance Parameters Parameter Value Unit V 100 V DS @ T j,max R 6.3 DS(on),max m Q 60.7 nC g,typ I 396 A D,pulse 3. Packaging and Internal Circuit Part Name Package Marking AUN063N10 DFN5X6 AUN063N10 DFN5X6 AUN063N10 1 Maximum ratings at Tj = 25 C, unless otherwise specified Table 2 Maximum ratings Values Parameter Symbol Unit Note / Test Condition Min. Typ. Max. Continuous drain current1) ID A - 123 TC=25 C Pulsed drain current2) I - - 396 A TC=25 C D,pulse Avalanche energy, single pulse E - - 24
