650V, 15A, 156m N-channel Power Super Junction MOSFETJMH65R190PCFDProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParameters Value Unit 100% UIS TestedVDSS 650 V 100% Vds TestedVGS(th)_Typ 3.4 V Halogen-free; RoHS-compliantID(@VGS=10V) 15 ARDS(ON)_Typ(@VGS=10V 156 mWApplications SMPS with PFC Flyback and LLC topologies Silver ATX,adapter,TV,lighting,Telecom DG STO-220-3L Top ViewSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice Marking MSL Form Package Tube(pcs)(pcs)JMH65R190PCFD-U H65R190PF N/A Tube TO-220-3L 50 5000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Symbol Parameter Value UnitVDS Drain-to-Source Voltage 650 VVGS Gate-to-Source Voltage 30 VTC = 25 15CID Continuous Drain Current ATC = 100 10CIDM Refer to Fig.4 APulse
