JMSH0602AEQ60V 2.0m N-Ch Power MOSFETFeaturesProduct SummaryParameter Value Unit Ultra-low RDS(ON) VDS60 V Low Gate Charge VGS(th)_Typ2.8 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 224 A RDS(ON)_Typ (@ VGS = 10V)2.0 Pb-free Lead Plating m Halogen-free and RoHS-compliant AEC-Q101 Qualified for Automotive ApplicationsTO-263-3L Top ViewDDGGSSOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH0602AEQ-13 TO-263-3L 8 SH0602AQ 1 -55 to 175 13-inch Reel 800Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 60 VGate-to-Source Voltage VGS 20 VTC = 25C 224Continuous DrainID ACurrent (1) TC = 100C 158IDM 832Pulsed Drain Current (2) AEAS 338Avalanche Energy (3) mJTC = 25
