Скачать даташит для jmsh1001btl:

JMSH1001BTL100V 1.7m TOLL N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Ultra-low RDS(ON) VDS100 V Low Gate Charge VGS(th)_Typ2.8 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 300 A RDS(ON)_Typ (@ VGS = 10V) Pb-free Lead Plating 1.7 m Halogen-free and RoHS-compliantApplications Power Managerment in Telecom., Industrial Automation, CE Current/Voltage Switching in DC/DC & AC/DC Sub-systems Motor Driving or BMS in Power Tool, E-vehicle, RoboticsPowerJE10x12 Top PowerJE10x12 Bottom DrainTabDGatePin 1SPin 1Source GPins28Pin 1Ordering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1001BTL-13PowerJE10x12 (1) 8 SH1001B 1 -55 to 175 13-inch Reel 2000Note 1: PowerJE is a registered trademark of JieJie Micro., its package out
