JMSH1504CTL150V 3.3m TOLL N-Ch Power MOSFETProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)Parameter Value Unit VDS150 V Low Gate Charge, Qg VGS(th)_Typ3.5 V 100% UIS and Rg Tested ID (@ VGS = 10V) (2) 252 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)3.3 m Halogen-free and RoHS-compliantApplications Power Management in Computing, CE, IE 4.0, Communications Current Switching in DC/DC & AC/DC (SR) Sub-systems Load Switching, Quick/Wireless Charging, Motor DrivingPowerJE10x12 Top View PowerJE10x12 Bottom ViewDrainTabGatePin 1SPin 1Source GPins 2-8Pin 1Ordering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1504CTL-13 8 SH1504C 1 -55 to 175 13-inch Reel 2000PowerJE10x12 (1)Note 1: PowerJE is a registered trademark of JieJie Micro., its
