JMSH1507PCJMSH1507PE150V 5.0mW N-Ch Power MOSFETFeaturesProduct SummaryParameter Value Unit Ultra-low RDS(ON) VDS150 V Low Gate Charge VGS(th)_Typ3.2 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 133 A RDS(ON)_Typ (@ VGS = 10V) Halogen-free and RoHS-compliant 5.0 mWApplications Power Managerment in Telecom., Industrial Automation, CE Current Switching in DC/DC & AC/DC (SR) Sub-systems Motor Driving in Power Tool, E-vehicle, RoboticsTO-220-3L Top ViewTO-263-3L Top ViewDDGG GDSSSOrdering InformationDevice Package # of Pins Marking MSL TJ ( Media Quantity (pcs)C)JMSH1507PC-U TO-220-3L 3 SH1507P NA -55 to 150 Tube 50JMSH1507PE-13 TO-263-3L 3 SH1507P 3 -55 to 150 13-inch Reel 800Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Sour
