JMSH1535AGQ150V 27m N-Ch Power MOSFETFeatures Product SummaryParameter Value Unit Low ON-resistance, RDS(ON) VDS150 V Low Gate Charge, Qg VGS(th)_Typ3.3 V 100% UIS and Rg Tested ID (@ VGS = 10V) (1) 29 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)27 m Halogen-free and RoHS-compliant AEC-Q101 Qualified for Automotive Applications PDFN5x6-8LPin ConfigurationTop ViewBottom ViewTop ViewD1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1535AGQ-13 PDFN5x6-8L 8 SH1535AQ 1 -55 to 175 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 150 VGate-to-Source Voltage VGS 20 VTC = 25C 29Continuous DrainID ACurrent (1) TC = 100C 21IDM 117Pulsed
