JMSL0401AGQ40V 1.3mW N-Ch Power MOSFETFeatures Product SummaryParameter Value Unit Ultra-low ON-resistance, RDS(ON) VDS40 V Low Gate Charge, Qg VGS(th)_Typ1.6 V 100% UIS and Rg Tested ID (@ VGS = 10V) (1) 198 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)1.3 mW RDS(ON)_Typ (@ VGS = 4.5V)1.7 mW Halogen-free and RoHS-compliant AEC-Q101 Qualified for Automotive Applications PDFN5x6-8LPin ConfigurationTop ViewBottom ViewTop ViewD18 DS2S 7 DG 3S 6 D4G 5 DSOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0401AGQ-13 PDFN5x6-8L 8 SL0401AQ 1 -55 to 175 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 40 VGate-to-Source Voltage VGS 20 VTC = 25 198CConti
