40V, 163A, 2.9m N-channel Power SGT MOSFETJMSL0402TGProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 40 V 100% Vds TestedVGS(th)_Typ 1.7 V Halogen-free; RoHS-compliantID(@VGS=10V) 163 ARDS(ON)_Typ(@VGS=10V 1.9 mWApplications RDS(ON)_Typ(@VGS=4.5V 2.9 mW Load Switch PWM Application Power Management18 DS2S 7 D3 DS 64G 5 DPDFN5X6-8LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSL0402TG-13 PDFN5x6-8LSL0402T 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 40 VVGS Gate-to-Source Voltage 20 VTC = 25 163CIDContinuous Drain Current ATC = 100 103CIDM Refer to Fig
