INCHANGE Semiconductorisc Silicon NPN Power Transistor 2SD331DESCRIPTIONCollector-Emitter Breakdown Voltage-: V = 50V(Min)(BR)CEOLow Collector-Emitter Saturation Voltage-: V = 1.0V(Max) @I = 2.0ACE(sat) CComplement to Type 2SB515Minimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSEspecially suited for use in output stage of 10W AF poweramplifier.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Collector-Base Voltage 50 VCBOV Collector-Emitter Voltage 50 VCEOV Emitter-Base Voltage 5 VEBOI Collector Current-Continuous 2 ACI Collector Current-Peak 5 ACMCollector Power Dissipation1.75@ T =25aP WCCollector Power Dissipation20@ T =25CT Junction Temperature 150 JStorage Temperature Range -55~150 Tstg1isc websitewww.iscsemi.co
