AP3405GH-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Lower Gate Charge BVDSS -30V Simple Drive Requirement RDS(ON) 90m Fast Switching Characteristic ID -8.6AG RoHS Compliant & Halogen-FreeSDescriptionAdvanced Power MOSFETs from APEC provide theGDdesigner with the best combination of fast switching, TO-252(H)Sruggedized device design, low on-resistance and cost-effectiveness.The TO-252 package is widely preferred for commercial-industrialsurface mount applications and suited for low voltage applicationssuch as DC/DC converters.Absolute Maximum RatingsSymbol Parameter Rating UnitsVDS Drain-Source Voltage -30 VVGS Gate-Source Voltage +20 VContinuous Drain Current, VGS @ 10VID@TC=25 -8.6 AContinuous Drain Current, VGS @ 10VID@TC=100 -5.4 AIDM Pulsed Drain Curren
