CHENMKO ENTERPRISE CO.,LTDCHTA92LGPSURFACE MOUNT High Voltage PNP Transistor VOLTAGE 300 Volts CURRENT 500 mAmpereAPPLICATION* Small Signal Amplifier .FEATURESOT-23* Surface mount package. (SOT-23)* Low saturation voltage VCE(sat)=-0.5V(max.)(IC=-20mA) * Low cob. Cob=6.0pF(Typ.)* PD= 300mW (mounted on ceramic substrate).* High saturation current capability.(1)(3)CONSTRUCTION(2)* PNP Silicon Transistor* Epitaxial planner type( ) ( ).055 1.40 .028 0.70( ) ( ).047 1.20 .020 0.50( ).103 2.64MARKING.086 (2.20)* PA( )(3) .045 1.15CCIRCUIT( ).033 0.85(1) BE (2)Dimensions in millimeters SOT-23MAXIMUM RATINGES ( At TA = 25oC unless otherwise noted )RATINGS CONDITION SYMBOL MIN. MAX. UNITSCollector - Base Voltage Open Emitter VCBO - -300 VoltsCollector - Emitter Voltage Open Base VCEO - -300 VoltsEmitter - Base
