HUF76629D3, HUF76629D3SData Sheet December 200120A, 100V, 0.054 Ohm, N-Channel, Logic Level UltraFET Power MOSFETPackagingJEDEC TO-251AA JEDEC TO-252AAFeatures Ultra Low On-ResistanceDRAINSOURCE (FLANGE) - rDS(ON) = 0.052, VGS = 10VDRAIN- rDS(ON) = 0.054, VGS = 5VGATE Simulation ModelsGATE- Temperature Compensated PSPICE and SABER SOURCEElectriecal ModelsDRAIN (FLANGE)- Spice and SABER Thermal Impedance Models- www.fairchildsemi.comHUF76629D3 HUF76629D3S Peak Current vs Pulse Width Curve UIS Rating CurveSymbol Switching Time vs RGS CurvesDOrdering InformationPART NUMBER PACKAGE BRANDGHUF76629D3 TO-251AA 76629DHUF76629D3S TO-252AA 76629DSNOTE: When ordering, use the entire part number. Add the suffix T to obtain the variant in tape and reel, e.g., HUF76629D3ST.Absolute Maximum Ratings TC
