Скачать даташит для irfb59n10dpbf_irfs59n10dpbf:

PD - 95378IRFB59N10DPbF IRFS59N10DPbFSMPS MOSFET IRFSL59N10DPbFHEXFET Power MOSFETApplicationsl High frequency DC-DC convertersVDSS RDS(on) max IDl UPS / Motor Control Inverters 100V 0.025 59Al Lead-FreeBenefitsl Low Gate-to-Drain Charge to ReduceSwitching Lossesl Fully Characterized Capacitance IncludingEffective COSS to Simplify Design, (SeeApp. Note AN1001)TO-220ABD2Pak TO-262l Fully Characterized Avalanche VoltageIRFB59N10DIRFS59N10D IRFSL59N10Dand CurrentAbsolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V 59ID @ TC = 100C Continuous Drain Current, VGS @ 10V 42 AIDM Pulsed Drain Current 236PD @TA = 25C Power Dissipation 3.8 WPD @TC = 25C Power Dissipation 200Linear Derating Factor 1.3 W/CVGS Gate-to-Source Voltage 30 Vdv/dt Peak Diode Recovery dv/dt
