PD - 95616AIRGB4B60KD1PbFIRGS4B60KD1PbFIRGSL4B60KD1PbFINSULATED GATE BIPOLAR TRANSISTOR WITHULTRAFAST SOFT RECOVERY DIODE CVCES = 600VFeatures Low VCE (on) Non Punch Through IGBT Technology.IC = 7.6A, TC=100C 10s Short Circuit Capability.G Square RBSOA.tsc > 10s, TJ=150C Positive VCE (on) Temperature Coefficient.E Maximum Junction Temperature rated at 175C.VCE(on) typ. = 2.1V Lead-Free n-channelBenefits Benchmark Efficiency for Motor Control. Rugged Transient Performance. Low EMI. Excellent Current Sharing in Parallel Operation.TO-220 D2Pak TO-262IRGB4B60KD1 IRGS4B60KD1 IRGSL4B60KD1Absolute Maximum RatingsParameter Max. UnitsVCES Collector-to-Emitter Voltage 600 VIC @ TC = 25C Continuous Collector Current 11IC @ TC = 100C Continuous Collector Current 7.6 AICM Pulse Collector Curre
