JMSL0302AG30V 1.3m N-Ch Power MOSFETFeatures Product SummaryParameter Typ. Unit Ultra-low RDS(ON) VDS30 V High Current Capability VGS(th)1.7 V ESD Enhanced to HBM Rating up to 1.5kV ID (@ VGS = 10V) (1) 178 A 100% UIS Tested, 100% Rg Tested RDS(ON) (@ VGS = 10V)1.3 m RDS(ON) (@ VGS = 4.5V)2.0 mApplications Power Management in Computing, CE, IE 4.0, Communications Current Switching in DC/DC & AC/DC Sub-systems Motor Driving, Quick/Wireless ChargingPDFN5x6Pin ConfigurationTop ViewBottom ViewTop ViewD1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0302AG-13 PDFN5x6 8 SL0302A 1 -55 to 150 13-inch Reel 3000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 30
