JMSL0302BU30V 1.5m N-Ch Power MOSFETFeaturesProduct SummaryParameter Value Unit Ultra-low RDS(ON) VDS30 V Low Gate Charge VGS(th)_Typ1.6 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 135 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)1.5 m RDS(ON)_Typ (@ VGS = 4.5V)2.2 m Halogen-free and RoHS-compliantApplications Power Management in Computing, CE, IE 4.0, Communications Current Switching in DC/DC & AC/DC Sub-systems Motor Driving, Quick/Wireless ChargingPDFN3x3-8LPin ConfigurationTop ViewBottom ViewTop ViewD 1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0302BU-13 PDFN3x3-8L 8 SL0302B 1 -55 to 150 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value Unit
