Скачать даташит для jmsl0315agd:

JMSL0315AGD30V 7.5m Dual N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Low RDS(ON) VDS30 V LowGateCharge VGS(th)_Typ1.7 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 37 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)7.5 m RDS(ON)_Typ (@ VGS = 4.5V)10.5 m Halogen-free and RoHS-compliantApplications Power Mgmt. in Computing, CE, Digital Lifestyle, IE 4.0, Communications Current Switching in DC/DC (H-bridge, Buck/Boost) & AC/DC (Inverting, SR) Load Switching over VBUS in Fast Charger, Half-bridging in Wireless Charger Motor Driving in Home Appliance, Robotics, VentilationPDFN5x6-8L-DPin ConfigurationChip-1 & Chip-2Top View Top ViewBottom ViewD1 D2G1 G2S1 S2Ordering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0315AGD-13 PDF
