JMSL0315AV30V 7.2m N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Low RDS(ON) VDS30 V Low Gate Charge VGS(th)_Typ1.6 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 22 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)7.2 m RDS(ON)_Typ (@ VGS = 4.5V)10.5 m Halogen-free and RoHS-compliantApplications Power Management in Computing, CE, IE 4.0, Communications Current Switching in DC/DC & AC/DC Sub-systems Motor Driving, Quick/Wireless ChargingU-DFN2020-6LTop ViewPin Configuration DTop View Bottom ViewG SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0315AV-7 U-DFN2020-6L 6 BM 1 -55 to 150 7-inch Reel 3000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 30 V
