KSH41C PNP EPITAXIAL SILICON TRANSISTORGENERAL PURPOSE AMPLIFIERD-PAKLOW SPEED SWITCHING APPLICATIONSD-PACK FOR SURFACE MOUNTAPPLICATIONS Load Formed for Surface Mount Application(No Suffix)1 Straight Lead (I.PACK, - I Suffix) Electrically Similar to Popular TIP41 and TIP41CABSOLUTE MAXIMUM RATINGS 1. Base 2. Collector 3. EmitterCharacteristic Symbol Rating UnitI-PAK Collector Base Voltage VCBO 100 V Collector Emitter Voltage VCEO 100 V Emitter Base Voltage VEBO 5 V Collector Current (DC) IC 6 A Collector Current (Pulse) IC 10 A1 Base Current IB 2 A Collector Dissipation ( TC=25 ) PC 20 W1. Base 2. Collector 3. EmitterPC 1.75 W Collector Dissipation (TA=25 ) Junction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 ELECTRICAL CHARACTERISTICS (Tc =25 )Characteristic Symbol Test Conditions Min Max Unit* Collector
