SSF4N60F Main Product Characteristics: VDSS 600V RDS(on) 1.9(typ.) ID 4A Marking and p in TO-220F Schematic diagram Assignment Features and Benefits: Advanced MOSFET process technology Special designed for PWM, load switching and general purpose applications Ultra low on-resistance with low gate charge Fast switching and reverse body recovery 150 operating temperature Description: It utilizes the latest processing techniques to achieve the high cell density and reduces the on-resistance with high repetitive avalanche rating. These features combine to make this design an extremely efficient and reliable device for use in power switching application and a wide variety of other applications Absolute max Rating: Symbol Parameter Max. Units ID @ TC = 25 Continuous Drain Current, V @ 10V 4 C GSI @ TC = 100 Co
