PFT903N SCR-module DATASHEET

PFT903N ELECTRICAL SPECIFICATIONS



   Type: SCR-module
   Maximum peak gate power (P_GM): 1 W
   Maximum repetitive peak and off-state voltage (V_DRM): 800 V
   Maximum average on-state current (I_T(AVR)): 100 A
   Non repetitive surge peak on-state current (I_TSM): 2000 A
   Critical repetitive rate of rise of on-state current (dI/dt): 100 A/µs
   Critical rate of rise of off-state voltage (dV/dt): 500 V/µs
   Maximum operating junction and storage temperature range (T_stg, T_j): -40..150 °C
   Junction to case thermal resistance (R_TH(j-c)): 0.25 K/W
   Triggering gate voltage (V_GT): 2.5 V
   Peak on-state voltage drop (V_TM): 1.15 V
   Triggering gate current (I_GT): 100 mA
   Holding current (I_H): 80 mA



PFT903N Replacements

Type
	< PGM <		W
	< VDRM <		V
	< IT(AVR) <		A
	< IT(RMS) <		A
	< ITSM <		A
	< dI/dt <		A/µs
	< dV/dt <		V/µs
Tstg, Tj	>		°C
RTH(j-a)	<		K/W
RTH(j-c)	<		K/W
VGT	<		V
VTM	<		V
IGT	<		mA
IH	<		mA
Package			+ similar ones

 SEARCH - Replacements for SCR and Triac



PFT903N Datasheet

Page #1

Page #2

Description

PFT903N PFT906N THYRISTOR 90A Avg 300～600 Volts ■回路図　CIRCUIT ■外形寸法図　OUTLINE DRAWING （単位　Dimension：mm） 1 2 3 K2 G2 G1 K1 K3 G3 φ� φ� ■最大定格　Maximum Ratings 耐圧クラス　Grade 項　　　目 記号 単位 Parameter Symbol Unit PFT903N PFT906N くり返しピークオフ電圧 VDRM 300 600 V Repetitive Peak Off-State Voltage 非くり返しピークオフ電圧 VDSM 400 700 V Non Repetitive Peak Off-State Voltage �
