View 18n50 datasheet:

18n5018n50

UNISONIC TECHNOLOGIES CO., LTD 18N50 Power MOSFET 18A, 500V N-CHANNEL POWER MOSFET 11TO-230 TO-220F1 DESCRIPTION The UTC 18N50 is an N-channel enhancement mode power MOSFET using UTCs advanced planar stripe andDMOS technology to provide perfect performance. This technology can withstand high energy pulse in the avalanche and commutation mode. It can provide minimum 11on-state resistance and high switching speed. TO-220F2 TO-220This device is generally applied in active power factor correction and high efficient switched mode power supplies. FEATURES * RDS(ON)=0.32 @ VGS=10V * High switching speed 11* Typically 45nC low gate charge * 100% avalanche tested TO-3P TO-263* Typically 25pF low CRSS * Improved dv/dt capability SYMBOL ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Fr
