View 2n2221aubc datasheet:

TECHNICAL DATA SHEET 6 Lake Street, Lawrence, MA 01841 1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803 Website: http: //www.microsemi.com NPN SILICON SWITCHING TRANSISTOR Qualified per MIL-PRF-19500/255 DEVICES LEVELS 2N2221A 2N2222A JAN2N2221AL 2N2222AL JANTX2N2221AUA 2N2222AUA JANTXV2N2221AUB 2N2222AUB JANS 2N2221AUBC * 2N2222AUBC * * Available to JANS quality level only. ABSOLUTE MAXIMUM RATINGS (TC = +25C unless otherwise noted) Parameters / Test Conditions Symbol Value UnitCollector-Emitter Voltage VCEO 50 VdcCollector-Base Voltage VCBO 75 VdcEmitter-Base Voltage VEBO 6.0 VdcCollector Current IC 800 mAdcTO-18 (TO-206AA) Total Power Dissipation @ TA = +25C PT 0.5 W2N2221A, 2N2222A Operating & Storage Junction Temperature Range Top, Tstg -65 to +200 CTHERMAL CHARACTERISTICS Parameters / Test Conditions Symbol Max. Unit T
