View 2n2906 7 datasheet:

2n2906_72n2906_7

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified CompanyPNP SILICON PLANAR SWITCHING TRANSISTORS 2N2906 2N2907 TO-18 Metal Can PackageSwitching and Linear ApplicationABSOLUTE MAXIMUM RATINGSDESCRIPTION SYMBOL VALUE UNITVCEOCollector Emitter Voltage 40 VVCBOCollector Base Voltage 60 VVEBOEmitter Base Voltage 5 VICCollector Current Continuous 600 mAPower Dissipation @ Ta=25C PD 400 mWDerate Above 25C 2.28 mW/ CPower Dissipation @ Tc=25C PD 1.8 WDerate Above 25C 10.3 mW/ COperating and Storage Junction Tj, Tstg - 65 to +200 CTemperature RangeELECTRICAL CHARACTERISTICS (Ta=25C unless specified otherwise )DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT*VCEO IC=10mA, IB=0Collector Emitter Voltage 40 VVCBOCollector Base Voltage IC=10A, IE=0 60 VVEBOEmitter Base Voltage IE=10A,
