View 2n2907aub datasheet:

2n2907aub2n2907aub

Product Bulletin JANTX, JANTXV, 2N2907AUBSeptember 1996Surface Mount PNP General Purpose TransistorType JANTX, JANTXV, 2N2907AUBFeatures Absolute Maximum Ratings (TA = 25o C unless otherwise noted)Collector-Base Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 VCeramic surface mount packageCollector-Emitter Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 VMiniature package to minimize circuitEmitter-Base Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0 Vboard areaCollector Current-Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 600 mAHermetically sealedOperating Junction Temperature (T ). . . . . . . . . . . . . . . . . . . . . . . . -65o C to +200o CJ
