View 2n3772 datasheet:

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company2N3772NPN SILICON PLANAR POWER TRANSISTORTO-3Metal Can PackageDesigned for Linear Amplifiers, Series Pass Regulators, and Inductive Switching Applications.ABSOLUTE MAXIMUM RATINGS DESCRIPTION SYMBOL UNITSVALUECollector Base Voltage VCBO V100Collector Emitter Voltage VCEO V60Collector Emitter Voltage VCEX V80Emitter Base Voltage VEBO 7 VCollector Current Continuous IC 20 APeak 30Base Current Continuous IB 5 APeak 15Power Dissipation @ Tc=25C PD 150 WDerate Above 25C 0.855 W/COperating And Storage Junction Tj, Tstg - 65 to +200 CTemperature RangeTHERMAL RESISTANCERth(j-c)Junction to Case 0.170 C/WELECTRICAL CHARACTERISTICS (TC=25C unless specified otherwise)DESCRIPTION SYMBOL TEST CONDITION MIN MAX UNITSCollector Emitter Sustain
