View 2n4398 2n4399 2n5745 datasheet:

Inchange Semiconductor Product Specification Silicon PNP Power Transistors 2N4398 2N4399 2N5745 DESCRIPTION With TO-3 package Complement to type 2N5301/5302/5303 Low collector saturation voltage Excellent safe operating area APPLICATIONS For use in power amplifier and switching circuits applications. PINNING PIN DESCRIPTION1 Base 2 EmitterFig.1 simplified outline (TO-3) and symbol3 CollectorAbsolute maximum ratings(Ta=) SYMBOL PARAMETER CONDITIONS VALUE UNIT2N4398 -40VCBO Collector-base voltage 2N4399 Open emitter -60 V 2N5745 -80 2N4398 -40VCEO Collector-emitter voltage 2N4399 Open base -60 V 2N5745 -80 VEBO Emitter-base voltage Open collector -5 V 2N4398/4399 -30 IC Collector current A 2N5745 -20 IB Base current -7.5 APD Total power dissipation TC=25 200 W Tj Junction temperature 200 Tstg Storage tempe
