View 2n5401 datasheet:
2N5401 -0.6 A, -160 V PNP Plastic Encapsulated Transistor Elektronische Bauelemente RoHS Compliant Product A suffix of -C specifies halogen & lead-free TO-92 FEATURES G H Switching and amplification in high voltage Applications such as telephony J Low current (max. 600mA) A DMillimeter REF. Min. Max. B High voltage (max. 160V) A 4.40 4.70 B 4.30 4.70 KC 12.70 - D 3.30 3.81 E 0.36 0.56 F 0.36 0.51 E C FG 1.27 TYP. H 1.10 - Collector J 2.42 2.66 K 0.36 0.76 3 2 Base 1 Emitter ABSOLUTE MAXIMUM RATINGS (TA = 25C unless otherwise specified) PARAMETER SYMBOL RATING UNIT Collector to Base Voltage VCBO -160 V Collector to Emitter Voltage VCEO -150 V Emitter to Base Voltage VEBO -5 V Collector Current - Continuous IC -0.6 A Collector Power Dissipation PC 0.625 W Junction, Storage Temperature TJ,
