View 2n5401hr datasheet:
2N5401HRHi-Rel PNP bipolar transistor 150 V, 0.5 ADatasheet - production dataFeatures 3BVCEO 150 V11IC (max) 0.5 A223HFE at 10 V - 150 mA > 60 TO-18 LCC-33 Hermetic packages4 ESCC and JANS qualified1 Up to 100 krad(Si) low dose rate2UBDescriptionPin 4 in UB is connected to the metallic lid.The 2N5401HR is a silicon planar PNP transistor specifically designed and housed in hermetic Figure 1. Internal schematic diagrampackages for aerospace and Hi-Rel applications. It is available in the JAN qualification system (MIL-PRF19500 compliance) and in the ESCC qualification system (ESCC 5000 compliance). In case of discrepancies between this datasheet and the relevant agency specification, the latter takes precedence.Table 1. Device summaryQualification Device Agency specification Package Radiation level EPPLsys
