View 2n7002a datasheet:

2n7002a2n7002a

2N7002AN-CHANNEL ENHANCEMENT MODE FIELD EFFECT TRANSISTOR Please click here to visit our online spice models database. Features Mechanical Data N-Channel MOSFET Case: SOT-23 Low On-Resistance Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 Low Gate Threshold Voltage Moisture Sensitivity: Level 1 per J-STD-020D Low Input Capacitance Terminals: Solderable per MIL-STD-202, Method 208 Fast Switching Speed Lead Free Plating (Matte Tin Finish annealed over Copper Small Surface Mount Package leadframe). ESD Protected Gate, 1.2kV HBM Terminal Connections: See Diagram Lead, Halogen and Antimony Free, RoHS Compliant Marking Information: See Page 3 "Green" Device (Notes 2 and 4) Ordering Information: See Page 3 Qualified to AEC-Q101 Standards for High Reliabili
