View 2n7002dsgp datasheet:
CHENMKO ENTERPRISE CO.,LTD2N7002DSGPSURFACE MOUNTDual N-Channel Enhancement MOS FET VOLTAGE 50 Volts CURRENT 0.51 AmpereAPPLICATION* Servo motor control. * Power MOSFET gate drivers.* Other switching applications.FEATURESC-74/SOT-457* Small surface mounting type. (SC-74/SOT-457)* High density cell design for low RDS(ON). * Suitable for high packing density.(1) (6)* Rugged and reliable.* High saturation current capability.0.951.90.2 2.90.2* Voltage controlled small signal switch. 0.950.1 (3) (4)CONSTRUCTION0.30.050.21.60.1* Dual N-Channel EnhancementMARKING* 72D 0.10.150.06 1.10.20.10.80.10~0.10.3~0.66 42.80.2CIRCUIT1 3 Dimensions in millimeters SC-74/SOT-457Absolute Maximum Ratings TA = 25C unless otherwise notedSymbol Parameter 2N7002DSGP UnitsVDSS Drain-Source Voltage 50 VVDGR D
