View 2n7002e datasheet:
2N7002EN-Channel SMD MOSFET ESD Protection 60V N-Channel Enhancement Mode MOSFET- ESD ProtectionFeaturesPackage outline RDS(ON), VGS@10V, ID@500mA=3.0 RDS(ON), VGS@4.5V, ID@200mA=4.0 SOT-23 ESD protection 2V (Human body mode) Advanced trench process technology. High density cell design for ultra low on-resistance. Very low leakage current in off condition Specially designed for battery operated system, solid-state relays drivers, relays, displays, lamps, solenoids, memories, etc. (B)(C) In compliance with EU RoHS 2002/95/EC directives.(A) Suffix "-H" indicates Halogen-free part, ex. 2N7002E-H.0.063 (1.60)0.027 (0.67)0.047 (1.20) 0.013 (0.32)0.108 (2.75)Mechanical data0.083 (2.10) Epoxy:UL94-V0 rated flame retardant Case : Molded plastic, SOT-230.051 (1.30)0.035 (0.89) Terminals : Sold
