View 2n7002esegp datasheet:
CHENMKO ENTERPRISE CO.,LTD2N7002ESEGPSURFACE MOUNT N-Channel Enhancement Mode Field Effect Transistor VOLTAGE 60 Volts CURRENT 115 mAmpereAPPLICATION* Relay driver* High speed line driver* Logic level transistorSC-70/SOT-323FEATURE* Small surface mounting type. (SC-70/SOT-323)* High density cell design for low RDS(ON). * Suitable for high packing density.* Rugged and reliable.0.651.30.12.00.2* High saturation current capability. 0.65* ESD protect in input gate 1.5KV0.30.11.250.10.8~1.10.05~0.20~0.10.1Min.D32.0~2.45CIRCUIT1 GDimensions in millimeters SC-70/SOT-3232SAbsolute Maximum Ratings TA = 25C unless otherwise notedSymbolParameter 2N7002ESEGPUnitsVDSS Drain-Source Voltage60 VVGSS Gate-Source Voltage20 VMaximum Drain Current - Continuous 115IDmA- Pulsed (Note 1) 800PD Maximum Pow
