View 2n7002esgp datasheet:

2n7002esgp2n7002esgp

CHENMKO ENTERPRISE CO.,LTD2N7002ESGPSURFACE MOUNT N-Channel Enhancement Mode Field Effect Transistor VOLTAGE 60 Volts CURRENT 115 mAmpereAPPLICATION* Relay driver* High speed line driver* Logic level transistorSOT-23FEATURE* Small surface mounting type. (SOT-23)* High density cell design for low RDS(ON). * Suitable for high packing density.* Rugged and reliable.(1)* High saturation current capability.(3)* ESD protect in input gate 2.0KV(2)( ) ( ).055 1.40 .028 0.70( ) ( ).047 1.20 .020 0.50( ).103 2.64.086 (2.20)D( )3 .045 1.15CIRCUIT( ).033 0.851 GDimensions in inches and (millimeters) SOT-232SAbsolute Maximum Ratings TA = 25C unless otherwise notedSymbolParameter 2N7002ESGPUnitsVDSS Drain-Source Voltage60 VVGSS Gate-Source Voltage20 VMaximum Drain Current - Continuous 115IDmA- Pulsed
