View 2n7002k-3 datasheet:

SMD Type MOSFETN-Channel Enhancement MOSFET2N7002KSOT-23-3Unit: mm+0.22.9-0.1+0.10.4 -0.1Features3Low On-Resistance: RDS(ON)Low Gate Threshold VoltageLow Input Capacitance1 2D rain+0.02+0.10.15 -0.020.95 -0.1Fast Switching Speed+0.11.9-0.2Low Input/Output Leakage ESD Protected 2KV HBMGate1.Base1 GATE2.Emitter2 SOURCEGateProtectionSource 3 DRAINDiodeAbsolute Maximum Ratings Ta=25Parameter Symbol Rating UnitDrain-Source Voltage VDS 60VGate-Source Voltage -Continuous VGS 20Drain Current -Continuous ( Note:1) 300ID mA -Pulsed 800Power Dissipation (Note 1) PD 350 mWThermal Resistance.Junction- to-Ambient RthJA 357 /WJunction Temperature TJ 150Junction and Storage Temperature Range Tstg -55 to 150Notes: 1. Device mounted on FR-4 PCB.Electrical Characteristics Ta = 25Parameter Symb
