View 2n7002k-tp datasheet:
MCCTM Micro Commercial Components20736 Marilla Street ChatsworthMicro Commercial Components2N7002KCA 91311Phone: (818) 701-4933Fax: (818) 701-4939Features Epoxy meets UL 94 V-0 flammability rating Moisture Sensitivity Level 1 High density cell design for low RDS(ON) Voltage controlled small signal switch N-Channel MOSFET Rugged and reliable High saturation current capability Marking : 72K ESD Protected up to 2KV (HBM)Maximum Ratings @ 25OC Unless Otherwise Specified Symbol Rating Rating UnitSOT-23VDS Drain-source Voltage 60 VAVGS Gate-source Voltage 20 VD ID Drain Current 340 mA3PD Total Power Dissipation 350 mW 1.GATETJ Operating Junction Temperature -55 to +150 2. SOURCE BCTSTG Storage Temperature -55 to +150 3. DRAINRthJA Thermal Resistance fromJunction to Ambient 357 /W
