View 2n7002k datasheet:
2N7002KN-CHANNEL ENHANCEMENT MODE MOSFET Features Mechanical Data Low On-Resistance Case: SOT-23 Low Input Capacitance Case Material: Molded Plastic, Green Molding Compound. UL Flammability Classification Rating 94V-0 Fast Switching Speed Moisture Sensitivity: Level 1 per J-STD-020 Low Input/Output Leakage Terminals: Finish Matte Tin annealed over Alloy 42 Lead, Halogen and Antimony Free, RoHS Compliant "Green" leadframe. Solderable per MIL-STD-202, Method 208 Device (Notes 1 and 2) Terminal Connections: See Diagram ESD Protected Up To 2kV Weight: 0.008 grams (approximate) Qualified to AEC-Q101 Standards for High Reliability DrainSOT-23DGate GateG S ProtectionSource DiodeESD protected up to 2kV Top View Top View EQUIVALENT CIRCUITOrdering Information (Note 3) Pa
