CHENMKO ENTERPRISE CO.,LTD2N7002VGPSURFACE MOUNTDual N-Channel Enhancement MOS FET VOLTAGE 60 Volts CURRENT 0.280 AmpereAPPLICATION* Servo motor control. * Power MOSFET gate drivers.* Other switching applications.FEATURESOT-563* Small surface mounting type. (SOT-563)* High density cell design for low RDS(ON)* Suitable for high packing density.(1)(S1) (D1)(6)* Rugged and reliable.* High saturation current capability. (G1) 0.501.00.1 1.60.1* Voltage controlled small signal switch. (G2)0.50(D2)(S2)(4)0.05CONSTRUCTION0.250.1 (3)0.051.200.1* Dual N-Channel EnhancementMARKING* V70.550.050.140.04(6)D1 G2 (4)S20.1CIRCUIT 1.60.05(1) D2(3) Dimensions in millimeters SOT-563S1 G1Absolute Maximum Ratings TA = 25C unless otherwise noted2N7002VGPSymbol Parameter UnitsVDSS Drain-Source Voltage 60
